Size | 15×15×20 mm |
Camera apparatus | 1/4 picture sensor |
System | PAL/CCIR NTSC/EIA |
Validity pixel | PAL 628×582 NTSC 510×492 |
Picture area | PAL 5.78×4.19mm NTSC:4.69×3.45mm |
Horizontal definition | 380line |
Scan frequency | PAL/CCIR 50HZ NTSC/EIA 60HZ |
Minimum illumination | 3LUX |
Sensitivity | +18DB-AGL ON-OFF |
Output power | 300mW/50mW |
Frequency control | adopt CPU frequency lock the wreath to control, with high frequency stability |
Transmission signal | Picture / Sound |
Deliver the distance | 50/100M |
Voltage | DC+9V |
Current | 200mA |
Power consumption | 640mW |
